Alkyd Resin Plant Manufacturer
We are one of the topmost manufacturers and exporters of Alkyd Resin Production Plant. Manufactured in adherence to the international standards of quality, these production plants are known for their high performance, minimum power consumption, longer operational life and sturdy construction. These production plants can be customized as per the specifications provided by the customers.
SPECIFICATION
| Capacity | 50 L TO 20,000 LITER |
| Machinery in Plant | Chemical Reactor , Column , Condenser , Receiver & blender |
| Reactor Type | Both Dish End , Motor and Gear box , Inside Agitator for Mixing Material , Bottom discharge connection Vertical outer heating limpet and jacketed |
| Usage/Application | Reaction , Mixing or Blending Row Material |
| Mixing Material | Chemicals / Oils / Lubricant / Liquid Syrup / Sugar Syrup / Wax Melting /Engine Oil |
| Material of Construction | Stainless Steel ,Mild Storage |
| Orientation | Vertical Orientation |
| Shape | Round |
| Tank Diameter | As Per Your Requirement |
| Electric Heater | Single Phase or Three Phase |
| Temperature Controller | Automatic or PLC Operated |
| Mixing Speed (RPM) | Variable , Speed Up And Down As Per Requirement |
| Finishing Type | Matt Type ,Mirror Finishing |
| Heating and Cooling System | YES |
| Temperatures Range | 30 TO 250 Degree |
| Vacuum | Yes |
| Cooling Coil | Internal Coil |
| Outer | Heating coil or jacket |
| Plat Foam | Mild Steel |
Application Industry
- Pharmaceutical industry
- Chemical industry
- Food and beverages industry
- Petro-chemical industry
- Resins industry
- Polymers industry
- Coatings industry
- Adhesives industry
- Agricultural industry
- General chemicals industry
- Plastics industry
- Rubber industry
- Herbal Extractor
*Technical Parameter:
| Reaction Pot | Vertical Fractionating column | Horizontal Condenser | Separator | ||||
| Specification(L) | Size of Fractionating column(mm) | Stuff Volume (m3) |
Cooling Area (m2) |
Specification (mm) |
Condensation Area (m2) |
Specification (mm) |
Volume (L) |
| 300L | Φ159×560 | 0.01 | 0.22 | Φ219×1000 | 2.4 | Φ410×450 | 60 |
| 500L | Φ159×750 | 0.015 | 0.29 | Φ219×1500 | 3.6 | Φ410×450 | 60 |
| 1000L | Φ194×800 | 0.025 | 0.62 | Φ273×1500 | 5 | Φ410×450 | 60 |
| 1500L | Φ194×850 | 0.025 | 0.62 | Φ273×2000 | 6.5 | Φ410×450 | 60 |
| 2000L | Φ219×1000 | 0.035 | 1.0 | Φ325×2000 | 8 | Φ600×600 | 150 |
| 3000L | Φ273×1100 | 0.058 | 1.2 | Φ325×2000 | 10 | Φ600×600 | 150 |
| 5000L | Φ273×1200 | 0.065 | 1.5 | Φ377×2000 | 15 | Φ700×750 | 300 |
| 8000L | Φ325×1500 | 0.065 | 4 | Φ426×2000 | 20 | Φ700×750 | 300 |
| 10000L | Φ325×1800 | 0.07 | 5 | Φ426×3000 | 30 | Φ700×750 | 300 |
| 15000L | Φ377×1800 | 0.08 | 6 | Φ450×3000 | 40 | Φ800×750 | 500 |
| 20000L | Φ377×1800 | 0.08 | 6 | Φ450×3000 | 50 | Φ800×750 | 500 |
| 25000L | Φ377×2000 | 0.12 | 10 | Φ455×3000 | 60 | Φ800×750 | 500 |
| 30000L | Φ377×2000 | 0.12 | 10 | Φ475×3000 | 80 | Φ800×750 | 500 |
